UCSB-VIC-M84-4P - Refurbished - Cisco UCS VIC 1480 mezzanine adapter
Warranty: Lifetime
Condition: Refurbished
The Cisco UCS Virtual Interface Card (VIC) 1480, part number UCSB-VIC-M84-4P, is a mezzanine adapter designed for Cisco UCS B-Series M5 and M6 Blade Servers. It provides high-bandwidth connectivity with support for both Ethernet and Fibre Channel over Ethernet (FCoE) protocols.
Key Specifications:
-
Data Transfer Rate: Single-port 40 Gbps or 4x10 Gbps Ethernet/FCoE.
-
Media Type Supported: Optical Fiber.
-
Network Technology: 40GBase-X.
-
Expansion Slots: Two SFP28 slots.
-
Form Factor: Plug-in mezzanine card.
-
Dimensions: Height: 1.3 inches; Width: 2.9 inches.
Compatibility:
The VIC 1480 is compatible with the following Cisco servers:
-
UCS B200 M5 Blade Server
-
B480 M5 Blade Server
-
Various SmartPlay Select B200 M5 configurations.
This adapter enables a policy-based, stateless server infrastructure, allowing dynamic configuration of interfaces as either Network Interface Cards (NICs) or Host Bus Adapters (HBAs).
Condition: Refurbished
The Cisco UCS Virtual Interface Card (VIC) 1480, part number UCSB-VIC-M84-4P, is a mezzanine adapter designed for Cisco UCS B-Series M5 and M6 Blade Servers. It provides high-bandwidth connectivity with support for both Ethernet and Fibre Channel over Ethernet (FCoE) protocols.
Key Specifications:
-
Data Transfer Rate: Single-port 40 Gbps or 4x10 Gbps Ethernet/FCoE.
-
Media Type Supported: Optical Fiber.
-
Network Technology: 40GBase-X.
-
Expansion Slots: Two SFP28 slots.
-
Form Factor: Plug-in mezzanine card.
-
Dimensions: Height: 1.3 inches; Width: 2.9 inches.
Compatibility:
The VIC 1480 is compatible with the following Cisco servers:
-
UCS B200 M5 Blade Server
-
B480 M5 Blade Server
-
Various SmartPlay Select B200 M5 configurations.
This adapter enables a policy-based, stateless server infrastructure, allowing dynamic configuration of interfaces as either Network Interface Cards (NICs) or Host Bus Adapters (HBAs).
